Copper Texture 2 Pole Contactor 24 Volt Coil 50 / 60Hz ST2-0910

Product Categories

WENZHOU SANTUO ELECTRICAL CO.,LTD.

Contact Now

Copper Texture 2 Pole Contactor 24 Volt Coil 50 / 60Hz ST2-0910

Name: Copper Texture 2 Pole Contactor 24 Volt Coil 50 60Hz ST20910
Brand: SONTUOEC, WZSTEC
Price: 1 USD

Brand Name : SONTUOEC, WZSTEC

Model Number : ST2

Certification : CE

Place of Origin : China

MOQ : 500pcs

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000pcs/day

Standard : lEC 60947-1

In : 9,12,18,25,32,40,50,65,80,95A

Frequency : 50Hz,60Hz,50/60Hz

Color : White and black

Credential : CE

Texture : Copper

Contact Now

Copper Texture 2 Pole Contactor 24 Volt Coil 50 / 60Hz ST2-0910

ST2(New model LC1-D) Series AC Contactor is suitable for using in the circuits the rated voltage up to 660V AC 50Hz or 60Hz, rated current up to 95A, for making & breaking, frequently starting & controlling the AC motor. Combined with the auxiliary contact block, timer delay & machine- interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter. The Contactor is produced according to IEC 60947-1.

2. Specification
2. Specification
Type		ST2-09	ST2-12	ST2-18	ST2-25	ST2-32	ST2-40	ST2-50	ST2-65	ST2-80	ST2-95
Type		ST2-09	ST2-12	ST2-18	ST2-25	ST2-32	ST2-40	ST2-50	ST2-65	ST2-80	ST2-95
Rated workingcurrent(A)	AC3	9	12	18	25	32	40	50	65	80	95
Rated workingcurrent(A)	AC4	3.5	5	7.7	8.5	12	18.5	24	28	37	44
Standardpower ratingsof 3-phasemotors50/60Hz incategory AC-3	220/230V	2.2	3	4	5.5	7.5	11	15	18.5	22	25
	380/400V	4	5.5	7.5	11	15	18.5	22	30	37	45
	415V	4	5.5	9	11	15	22	25	37	45	45
	500V	5.5	7.5	10	15	18.5	22	30	37	55	55
	660/690V	5.5	7.5	10	15	18.5	30	33	37	45	55
Rated heat current(A)		20	20	32	40	50	60	80	80	125	125
Electrical life	AC3(x10⁴)	100	100	100	100	80	80	60	60	60	60
Electrical life	AC4(x10⁴)	20	20	20	20	20	15	15	15	10	10
Mechanical life (x10⁴)		1000	1000	1000	1000	800	800	800	800	600	600
Number of the contacts	3P+NO					3P+NC+NO
Number of the contacts	3P+NC					3P+NC+NO

Copper Texture 2 Pole Contactor 24 Volt Coil 50 / 60Hz ST2-0910

Delivery :

Copper Texture 2 Pole Contactor 24 Volt Coil 50 / 60Hz ST2-0910
